Embedded 5G industrial module at 90 x 72 x 15mm. DIN rail mount, 3.9W typical, 5-24VDC. For OEM panel builders and machine manufacturers adding 5G.
Cellular
5G NR SA/NSA Sub-6 GHz, 4G LTE
UK Bands
N1, N3, N7, N8, N20, N28, N38, N77, N78
Power Input
5-24 VDC (3.9W typical)
IP Rating
IP30
Temperature
-40 to +70°C
Interfaces
1x GbE ETH, USB 3.0, GPS/GLONASS/BeiDou/Galileo
Applications
The Milesight UF31 is a compact embedded 5G module designed to go inside industrial equipment rather than beside it. At 90 x 72 x 15mm, it fits on a DIN rail inside a standard panel. At 3.9W typical consumption, it operates from panel supply rails without additional power regulation. Built-in GNSS provides location data alongside connectivity.
Applications
- Industrial panels requiring embedded 5G connectivity
- Kiosks, ATMs, vending machines, EV chargers
- OEM equipment manufacturers adding 5G to product lines
- 4G to 5G migration for existing embedded cellular equipment
- Vehicle and mobile equipment requiring compact 5G connectivity
Full Specification
| Model Number | UF31-504AG |
| Cellular Standard | 5G NR SA/NSA Sub-6 GHz, 4G LTE |
| UK Network Bands | N1, N3, N7, N8, N20, N28, N38, N77, N78 |
| Industrial Interfaces | 1x GbE ETH, USB 3.0, GPS/GLONASS/BeiDou/Galileo |
| Power Input | 5-24 VDC (3.9W typical) |
| Operating Temperature | -40 to +70°C |
| IP Rating | IP30 |
| Dimensions | 90 x 72 x 15 mm |
